1. Nhanganyaya
The YAESU FT-60R is a robust and versatile 144/430 MHz dual-band handheld transceiver designed for amateur radio enthusiasts. This manual provides essential information for the proper setup, operation, and maintenance of your FT-60R.
Key features include extensive receive-frequency coverage (108-520 MHz and 700-999.990 MHz, cellular blocked), a new-generation Emergency Automatic ID (EAI) system for Search-and-Rescue, a large LCD display, and a high power output of 5W. Its compact design makes it suitable for various outdoor and everyday activities.
Image 1: The YAESU FT-60R Two-Way Radio, a compact dual-band handheld transceiver.
2. Chii chiri muBhokisi
Upon unpacking your YAESU FT-60R, please verify that all the following items are included:
- YAESU FT-60R Transceiver
- Ni-MH Battery Pack (FNB-83, 7.2 V, 1,400 mAh)
- PA-48B Charger
- SBH-13 Charging Stand
- Antenna
- Ham Guides TM Quick Reference Card
3. Kutanga Setup
3.1 Kuiswa kwebhatiri uye kuchaja
Before initial use, install the FNB-83 Ni-MH battery pack into the designated compartment on the back of the transceiver. Connect the PA-48B charger to the SBH-13 charging stand and place the FT-60R in the stand. Ensure the radio is fully charged before operation. A full charge typically takes several hours.
3.2 Antenna Attachment
Carefully screw the supplied antenna onto the antenna connector located on the top of the transceiver. Turn clockwise until finger-tight. Do not overtighten to avoid damaging the connector.
4. Operating the FT-60R
4.1 Kudzima/Kubatidza Simba uye Kudzora Vhoriyamu
To power on the FT-60R, press and hold the power button (usually located on the top or side). Adjust the audio volume using the dedicated rotary knob.
4.2 Frequency and Channel Selection
The FT-60R supports dual-band operation on 144 MHz and 430 MHz amateur bands. It also features wide receive frequency coverage from 108 to 520 MHz and 700 to 999.990 MHz (cellular frequencies are blocked). Use the numeric keypad or the rotary dial to select desired frequencies or navigate through programmed memory channels.
4.3 Emergency Automatic ID (EAI) System
The EAI system is a new-generation feature specifically designed for Search-and-Rescue operations. This system allows for automatic identification in emergency situations. Refer to the detailed user manual for specific activation and usage instructions for the EAI feature.
4.4 Makiyi Anorongwa
The transceiver features several programmable keys that can be customized for frequently used functions, enhancing user convenience and quick access to essential operations. Consult the full user manual for programming details and available functions.
4.5 CTCSS/DCS Operation
The FT-60R supports split CTCSS/DCS (Continuous Tone-Coded Squelch System / Digital Code Squelch) and DCS encode-only capabilities. These features are used for selective calling and accessing repeaters that require a specific tone or code.
4.6 Scanning Functionality
The radio includes various scanning features, allowing you to monitor a range of frequencies or programmed memory channels. This enables efficient monitoring of active communications or specific broadcast types.
4.7 Weather Radio Function
The FT-60R is capable of receiving weather radio broadcasts, providing important weather alerts and informational updates directly to your device.
5. Kuchengeta
5.1 Kuchengeta Battery
To prolong the life of your Ni-MH battery pack (FNB-83), avoid both overcharging and deep discharging. It is recommended to fully discharge and recharge the battery periodically. Store the battery in a cool, dry place when not in use for extended periods.
5.2 Kuchenesa
To clean the exterior of the radio, wipe it with a soft, slightly damp cloth. Do not use harsh chemicals, abrasive cleaners, or solvents, as these can damage the casing and display. Ensure the radio is completely dry before use.
5.3 Kuramba Mvura
The FT-60R is designed to be water-resistant, offering protection against light splashes and rain. However, it is not waterproof. Avoid submerging the device in water or exposing it to heavy downpours for prolonged periods.
6. Kugadzirisa matambudziko
If you encounter issues with your FT-60R, consider the following common troubleshooting steps:
- Hapana Simba: Ensure the battery is fully charged and correctly installed. Check the power button for proper function.
- Kugamuchirwa Kwakashata / Kutapurirana: Verify the antenna is securely attached. Check the selected frequency and power settings. Ensure you are within effective range of a repeater or another station.
- Hapana Audio: Check the volume level. Ensure no headphones are connected if you expect audio from the internal speaker.
- Kiyibhodhi Haipinduri: Check if the keypad lock function is activated. Refer to the manual for unlocking procedures.
For more detailed troubleshooting steps and solutions to specific error messages, please refer to the comprehensive user manual provided with your product or visit the official YAESU support website.
7. Zvinotsanangurwa
| Feature | Tsanangudzo |
|---|---|
| Brand | YAESU |
| Model Number | FT-60R |
| Item Weight | 1.86 makirogiramu |
| Product Dimensions | 2 x 3 x 8 inches |
| Color | Nhema |
| Nhamba yeChannels | 1000 |
| Special Feature | Dual Band, Long Range, Rechargeable |
| Range yeFrequency (RX) | 108 to 520 MHz and 700 to 999.990 MHz (cellular blocked) |
| Frequency Range (TX) | 144 to 148 MHz and 430 to 440 MHz |
| Mvura Resistance Level | Mvura Inodzivirira |
8. Warranty & Tsigiro
The YAESU FT-60R comes with a 3-year warranty from the date of purchase, ensuring peace of mind regarding product quality and performance. This warranty covers manufacturing defects and ensures reliable operation of your transceiver.
Image 2: A badge indicating the product is covered by a 3-year warranty.
For technical assistance, warranty claims, or further product information, please visit the official YAESU website or contact their authorized customer support channels. Keep your proof of purchase for warranty validation.
