Product Overview
The Oxygenics Marvel Chrome Rain Shower Head (Model 57288) is designed to enhance your showering experience with its innovative features and robust construction. This fixed shower head offers 9 unique spray settings, including a distinctive Waterfall setting, and features a substantial 8-inch face for broad coverage. It is engineered to intensify water pressure, providing an efficient and satisfying flow.
Mufananidzo 1: Mberi view of the Oxygenics Marvel Chrome Rain Shower Head, showcasing its square design and multiple nozzles.
Zvinokosha:
- 9 Unique Spray Settings: Includes an innovative Waterfall setting for varied showering experiences.
- Kusvika Kwakawedzerwa: Extends 7.5 inches from the shower arm, providing added versatility.
- Pressure Boosting: Multi-Oxygenics engine technology intensifies water pressure for enhanced efficiency.
- Increased Height: Increases shower height by 3 inches, accommodating various user heights.
- Wide Coverage: Substantial 8-inch face delivers extreme spray coverage.
- Durable Construction: Made from Acrylonitrile Butadiene Styrene with a polished chrome finish.
Zvinotsanangurwa
| Brand | Oxygenics |
| Model Number | 57288 |
| Style | Mazuvano |
| Shape | Square |
| Material | Acrylonitrile Butadiene Yakajeka |
| Finish Type | Yakakwenenzverwa Chrome |
| Installation Type | Wall Mounted |
| Flow Rate | 1.8 GPM (6.8 L/min) Maximum; 1.35 GPM (5.11 L/min) Minimum at 45 PSI |
| Color | Chrome |
| Product Dimensions | 8.26"L x 8.02"W |
| Nhamba yeSettings | 9 |
| Item Weight | 2 makirogiramu |
| Inosanganisirwa Zvikamu | Plumber's Tape, Rain Shower Head |
| UPC | 010147572889 |
Setup uye Installation
This section provides general instructions for installing your Oxygenics Marvel Chrome Rain Shower Head. For specific plumbing configurations, consult a professional plumber.
Zvishandiso uye Zvishandiso Zvinodiwa (Zvisina Kubatanidzwa):
- Wrench inogadziriswa kana zvipenga
- Rag or Cloth (to protect finish)
- Thread Seal Tape (Plumber's Tape is included)
Kuisa Matanho:
- Gadzirira Ruoko rweShower: Ensure the existing shower arm is clean and free of any old thread seal tape or debris. If replacing an old shower head, unscrew it counter-clockwise and remove it.
- Apply Thread Seal Tape: Wrap the threads of the shower arm with the included plumber's tape. Wrap 3-4 times clockwise around the threads, ensuring a tight seal.
- Batanidza Musoro weShower: Carefully screw the Oxygenics Marvel Shower Head onto the taped threads of the shower arm. Turn clockwise by hand until it is finger-tight.
- Tighten with Wrench: Using an adjustable wrench or pliers, gently tighten the shower head an additional quarter to half turn. Use a rag or cloth to protect the chrome finish from scratches. Usaomese, as this can damage the shower head or plumbing.
- Tarisa uone Mavuza: Turn on the water supply and check for any leaks around the connection point. If leaks occur, tighten slightly more or reapply thread seal tape.
Figure 2: The Oxygenics Marvel Shower Head properly installed on a standard shower arm, ready for use.
Operating Instruction
The Oxygenics Marvel Shower Head features 9 distinct spray settings, allowing you to customize your showering experience. The settings are easily adjustable.
Kuchinja Spray Settings:
To change the spray pattern, locate the selector lever or dial on the perimeter of the shower head. Gently rotate this mechanism to cycle through the available settings. Each click or distinct position corresponds to a different spray pattern, including the unique Waterfall setting.
Figure 3: The shower head operating with a typical spray pattern, demonstrating water flow from multiple nozzles.
Figure 4: The shower head demonstrating its unique Waterfall spray setting, providing a broad, gentle cascade of water.
Figure 5: The shower head displaying a more concentrated spray pattern, ideal for targeted rinsing.
Flow Rate Information:
The shower head operates at a maximum flow rate of 1.8 Gallons Per Minute (GPM) or 6.8 Liters Per Minute (LPM). At 45 PSI, the minimum flow rate is 1.35 GPM (5.11 LPM). This design ensures efficient water usage while maintaining powerful pressure.
Maintenance
Regular cleaning and maintenance will ensure the longevity and optimal performance of your Oxygenics Marvel Shower Head.
Cleaning the Shower Head:
- Kuchenesa Nguva Dzose: To maintain the polished chrome finish, wipe the shower head with a soft cloth and mild soap and water solution. Rinse thoroughly with clean water and dry immediately to prevent water spots.
- Mineral Deposit Removal: If mineral deposits (limescale) build up on the nozzles, gently rub them with your finger or a soft brush. For stubborn deposits, soak the shower head in a solution of equal parts white vinegar and water for 30 minutes to an hour. Rinse thoroughly after soaking.
- Dzivisa Harsh Cleaners: Do not use abrasive cleaners, scouring pads, or chemical solvents, as these can damage the chrome finish and the Acrylonitrile Butadiene Styrene material.
Kugadzirisa matambudziko
This section addresses common issues you might encounter with your shower head.
| Dambudziko | Zvinogona Kukonzera | Solution |
|---|---|---|
| Low Water Pressure |
|
|
| Leaking from Connection |
|
|
| Uneven Spray Pattern |
|
|
Warranty uye Support
For warranty information or technical support regarding your Oxygenics Marvel Chrome Rain Shower Head, please contact Oxygenics directly.
While specific warranty details are not provided in this manual, most Oxygenics products come with a manufacturer's warranty covering defects in materials and workmanship. Please retain your proof of purchase for warranty claims.
Mugadziri: Oxygenics
For the most current support contact information, please visit the official Oxygenics website or refer to the packaging that came with your product.
