Osram 64150NL-2HB Night Breaker Laser H1 Halogen Bulbs Instruction Manual

1. Chigadzirwa Pamusoroview

The Osram Night Breaker Laser H1 Halogen Bulbs (Model: 64150NL-2HB) are designed to enhance your vehicle's lighting, providing superior visibility and a brighter, whiter light. These bulbs are ideal for drivers seeking improved road illumination and safety, especially in dark or challenging driving conditions.

Zvinokosha:

• Kupenya Kwakawedzerwa: Up to 150% more brightness compared to standard halogen bulbs.
• Extended Beam: Projects light up to 150 meters further, allowing for quicker reactions.
• Improved Light Color: Produces a brighter, whiter light for better contrast and clarity.
• Kuvaka kwakasimba: Engineered to withstand various road conditions for reliable performance.
• Kuisa Nyore: Direct fit for standard H1 halogen sockets, compatible with most vehicles.
• Eco Pack: Supplied as a 2-pack for balanced and consistent lighting across both headlamps.

Figure 1: Osram Night Breaker Laser H1 Halogen Bulbs (2-pack) and packaging.

2. Safety Information

Please read and understand all safety warnings before handling or installing the bulbs. Failure to follow these instructions may result in electric shock, burns, or damage to your vehicle.

• Always wear appropriate personal protective equipment, including safety glasses and gloves, when handling automotive bulbs.
• Ensure the vehicle's ignition is off and the headlights are cool before attempting installation or replacement.
• Avoid touching the glass part of the bulb with bare hands. Oils from your skin can create hot spots, reducing bulb life. If touched, clean with rubbing alcohol.
• Halogen bulbs operate at high temperatures. Allow sufficient time for bulbs to cool down before handling.
• Chengeta mababu kure nevana.
• Rasa magirobhu ekare zvine ungwaru maererano nemitemo yenzvimbo.

3. Kuiswa

The Osram Night Breaker Laser H1 Halogen Bulbs are designed for direct replacement of existing H1 halogen bulbs. Installation steps may vary slightly depending on your vehicle's make and model. Consult your vehicle's owner's manual for specific headlight assembly access instructions.

General Installation Matanho:

1. Svika Headlight Assembly: Open the vehicle's hood. Locate the back of the headlight assembly. You may need to remove a cover, battery, or other components to gain access.
2. Bvisa Simba: Disconnect the electrical connector from the back of the old H1 bulb.
3. Bvisa Old Bulb: Unclip or twist the retaining spring/clip that holds the bulb in place. Carefully pull the old bulb straight out from the headlight housing.
4. Isa Bhabhu Idzva: Without touching the glass, carefully insert the new Osram Night Breaker Laser H1 bulb into the headlight housing. Ensure the bulb is seated correctly and the locking tabs align with the housing.
5. Secure Bulb: Re-engage the retaining spring/clip to firmly hold the new bulb in place.
6. Reconnect Power: Batanidzazve chinobatanidza magetsi kune girobhu idzva.
7. Test Mashandiro: Turn on your vehicle's headlights to ensure the new bulbs are functioning correctly. Check both low and high beams.
8. Resemble: Reinstall any components removed to access the headlight assembly.

Figure 2: Close-up of the H1 Halogen Bulbs.

4. Kushanda

Once installed, the Osram Night Breaker Laser H1 bulbs operate like standard halogen headlights. They provide enhanced illumination for improved visibility during night driving and in adverse weather conditions.

• Use low beams for normal driving conditions and when approaching oncoming traffic.
• Use high beams for maximum visibility on unlit roads, ensuring no oncoming traffic is present.
• Always ensure your headlights are properly aimed to prevent dazzling other drivers. Professional adjustment may be required after installation.

Figure 3: Enhanced road illumination provided by the bulbs.

5. Kuchengeta

These halogen bulbs are designed for long-lasting performance. Regular maintenance of your vehicle's lighting system can help ensure optimal light output and safety.

• Periodically inspect your headlights for dirt, debris, or condensation. Clean the headlight lenses with a soft cloth and appropriate cleaner.
• Check bulb functionality regularly. If one bulb fails, it is recommended to replace both bulbs simultaneously to maintain balanced light output and color.
• Avoid using abrasive cleaners or harsh chemicals on headlight lenses or bulbs.

6. Kugadzirisa matambudziko

If you experience issues with your Osram Night Breaker Laser H1 bulbs, consider the following troubleshooting steps:

• Bhabhu risingavheneke kumusoro:
  • Check the electrical connection to ensure it is secure.
  • Inspect the vehicle's fuse box for a blown headlight fuse.
  • Iva nechokwadi chekuti girobhu rakaiswa zvakanaka mubhokisi.
• Dim or Uneven Light:
  • Ensure both bulbs are the same type and age for consistent performance.
  • Check for dirt or haze on the headlight lens.
  • Confirm proper bulb seating and alignment.
• Flickering:
  • Tarisa uone kuti hauna kubatanidza magetsi.
  • Inspect wiring for damage.

If problems persist after troubleshooting, consult a qualified automotive technician.

7. Zvinotsanangurwa

For more product information, you can visit the official Osram website via this link: Osram Product Information

8. Warranty uye Tsigiro

For warranty information and customer support, please refer to the official OSRAM websaiti kana kubata mutengesi wako. Chengetedza humbowo hwako hwekutenga kune chero vimbiso yewaranti.
