1. Nhanganyaya
The MOJOGEAR Mini XL 20,000 mAh Power Bank is a high-capacity portable charger designed to provide fast and efficient power to your mobile devices. With its compact design and multiple charging ports, it's an ideal companion for travel, outdoor activities, or daily use, ensuring your smartphones, tablets, and other compatible gadgets stay charged.
2. Safety Information
Please read and follow these safety guidelines carefully to ensure safe operation and prolong the life of your power bank:
- Do not expose the power bank to extreme temperatures (above 45°C or below 0°C), direct sunlight, or high humidity.
- Do not disassemble, modify, or attempt to repair the device yourself. This will void the warranty and may cause damage or injury.
- Chengetedza bhangi remagetsi kure nemvura uye zvimwe zvinwiwa.
- Dzivisa kudonhedza kana kuisa bhangi remagetsi kune simba rinokanganisa.
- Rasa bhangi remagetsi zvine hungwaru zvichienderana nemitemo yemuno. Usarirase pamwe chete nemarara emumba.
- The power bank has a capacity of 74 Wh, which is generally suitable for air travel. However, always check with your airline's specific regulations before flying.
3. Package Zviri mukati
Ona kuti zvinhu zvese zviripo mupasuru yako:
- MOJOGEAR Mini XL 20,000 mAh Power Bank
- 0.3m Micro USB Cable
- Mushandisi Chinyorwa (gwaro iri)
4. Chigadzirwa Pamusoroview
Familiarize yourself with the components of your MOJOGEAR Mini XL Power Bank:
Zvikamu:
- Zviratidzo zve LED: Four small LED lights on the top edge indicate the remaining battery level and charging status.
- USB-A Zviteshi zvekubuda (x2): Standard USB ports for charging various devices. These support Quick Charge 3.0.
- USB-C Kupinza/Kubuda Chiteshi (x1): A versatile port that can be used to charge the power bank or to charge compatible devices. This port supports USB Power Delivery.
- Micro USB Input Port (x1): Dedicated port for charging the power bank using the provided Micro USB cable.
5. Setup
Before using your MOJOGEAR Mini XL Power Bank for the first time, it is recommended to fully charge it.
- Connect the provided 0.3m Micro USB cable to the Micro USB input port on the side of the power bank.
- Batanidza rimwe divi reMicro USB cable kune adapta yemagetsi yeUSB (isina kuiswa) kana pachiteshi cheUSB chekombuta.
- The LED indicators will light up and blink, indicating that the power bank is charging. All four LEDs will remain solid when fully charged.
Alternatively, you can use a USB-C to USB-C cable (not included) to charge the power bank via its USB-C input/output port.
6. Operating Instructions
6.1. Kubhadharisa Zvishandiso Zvako
Kuti uchajise foni yako, tablet, kana zvimwe zvishandiso zvinoenderana nazvo:
- Connect your device's charging cable (e.g., USB-A to Lightning, USB-C to USB-C) to one of the power bank's output ports (USB-A or USB-C).
- Unganidza mumwe mugumo wekambo kune yako kifaa.
- The power bank will automatically begin charging your device. The LED indicators will show the remaining power level.
The power bank supports Quick Charge 3.0 via the USB-A ports and USB Power Delivery via the USB-C port for fast charging compatible devices.
6.2. Charging Multiple Devices Simultaneously
You can charge up to three devices at the same time using the two USB-A output ports and the USB-C input/output port.
6.3. Mamiriro eChiratidzo che LED
The four LED lights indicate the power bank's battery level:
- 4 Solid LEDs: 75% - 100% yachajwa
- 3 Solid LEDs: 50% - 75% yachajwa
- 2 Solid LEDs: 25% - 50% yachajwa
- 1 Yakasimba LED: 0% - 25% charged (recharge soon)
- Blinking LEDs: Indicates the power bank is currently being charged.
7. Kuchengeta
Proper care will ensure the longevity of your power bank:
- Kuchenesa: Wipe the surface of the power bank with a dry, soft cloth. Do not use harsh chemicals or abrasive materials.
- Kuchengeta: Chengetedza bhangi remagetsi munzvimbo inotonhorera, yakaoma kure nechiedza chezuva uye tembiricha yakanyanyisa.
- Battery Care: If the power bank is not used for extended periods, charge it at least once every three months to maintain battery health and prevent deep discharge.
8. Kugadzirisa matambudziko
If you encounter issues with your MOJOGEAR Mini XL Power Bank, refer to the following common problems and solutions:
| Dambudziko | Zvinogona Kukonzera | Solution |
|---|---|---|
| Power bank isingachaji | Loose cable connection; Faulty cable or adapter; Power source issue. | Ensure cables are securely connected. Try a different cable or power adapter. Test with a different power outlet or USB port. |
| Mudziyo hauchaji kubva kubhangi remagetsi | Power bank is depleted; Loose cable connection; Incompatible device; Faulty device cable. | Recharge the power bank. Check cable connections. Ensure your device is compatible. Try a different charging cable for your device. |
| Kuchaja zvishoma nezvishoma | Cable not supporting fast charging; Device not supporting fast charging; Charging multiple devices. | Use a cable that supports Quick Charge or Power Delivery. Ensure your device supports these fast charging protocols. Charging multiple devices simultaneously may reduce individual charging speeds. |
| Power bank feels warm during use | Kushanda kwakajairika panguva yekuchaja/kuburitsa. | A slight warmth is normal. If it becomes excessively hot, disconnect immediately and contact customer support. |
9. Zvinotsanangurwa
| Feature | Detail |
|---|---|
| Model | 20.000 mAh |
| Capacity | 20,000 mAh (74 Wh) |
| Kuumbwa kwebhatiri | Lithium-polymer |
| Input Ports | 1x Micro USB, 1x USB-C |
| Output Ports | 2x USB-A, 1x USB-C |
| Special Features | Quick Charge 3.0 (USB-A), USB Power Delivery (USB-C) |
| Max Charging Speed | Up to 18W (3A) |
| Dimensions (L x W x H) | 13.8 x 6.8 x 2.7 cm |
| Kurema | 408 magiramu |
| Inowirirana Devices | Smartphones, Tablets, E-readers, Action Cameras, Wireless Headphones |
10. Warranty uye Tsigiro
10.1. Ruzivo rweWaranti
The MOJOGEAR Mini XL 20,000 mAh Power Bank comes with a 2-makore waranti kubva pazuva rawakatenga. Iyi waranti inovhara zvikanganiso zvekugadzira uye matambudziko anokonzerwa nekushandiswa kwakajairika. Haivhari kukuvara kunokonzerwa nekushandiswa zvisizvo, tsaona, shanduko dzisina mvumo, kana njodzi dzechisikigo.
10.2. Mutengi Tsigiro
For any questions, technical assistance, or warranty claims, please contact MOJOGEAR customer service. Refer to the product packaging or the official MOJOGEAR websaiti yeruzivo rwechizvino-zvino.
