1. Nhanganyaya
Thank you for choosing the Swan SAF11DB 11L Digital Dual Basket Air Fryer. This appliance is designed to provide a healthier way to cook your favorite foods with little to no oil. Please read this instruction manual thoroughly before first use to ensure safe and efficient operation. Keep this manual for future reference.
Ruzivo Rwakakosha Chekuchengetedza:
- Gara uchiisa air fryer panzvimbo yakagadzikana, isingapisi.
- Usanyudze mudziyo, tambo, kana plug mumvura kana chero imwe mvura.
- Chengetedza vana uye mhuka dzinovaraidza kure nemudziyo panguva yekushanda.
- Iva nechokwadi chekufefetedza kwakaringana kwakatenderedza air fryer.
- Usavhare chero maburi emhepo.
- Bvisa mudziyo kana usiri kushandiswa uye usati wachenesa.
- Bvumira mudziyo kuti utonhore zvachose usati wabata kana kuchenesa.
2. Chigadzirwa Pamusoroview
The Swan SAF11DB features an 11-litre capacity with a removable divider, allowing for flexible single or dual basket cooking. Its digital touch screen and preset functions simplify meal preparation.
Mufananidzo 2.1: Mberi view of the Swan SAF11DB Air Fryer with both baskets pulled out, containing cooked food. The digital control panel is visible at the top.
Zvikamu Zvikuru:
- Main Unit: Dzimba imba yekudziya uye fan.
- Kuratidzwa kweDigital Touch Screen: For controlling settings and monitoring cooking progress.
- Chengetedza Knob: Used for adjusting temperature and time.
- Mabhasikiti ekubikira (x2): Removable baskets for food.
- Basket Divider: Allows conversion of the 11L basket into two 5.5L baskets.
- Crisper Trays: Inoiswa mumatengu kuti mhepo ifambe zvakanaka.
Mufananidzo 2.2: Yakaputika view showing the main basket, the removable divider, and the two crisper trays, illustrating how the unit can be configured for single or dual zone cooking.
3. Setup uye Kutanga Kushandisa
- Kuburitsa: Bvisai chitofu chemhepo pamwe nezvimwe zvese zviri mupakeji nokungwarira. Chengetai pakeji yacho kuti muzoichengetera kana kuti muitakure mune ramangwana.
- Kutanga Kuchenesa: Wash the cooking baskets, divider, and crisper trays with warm, soapy water. Rinse thoroughly and dry completely. Wipe the main unit with a damp jira.
- Kuiswa: Place the air fryer on a flat, stable, heat-resistant surface, ensuring at least 15 cm of clear space around the back and sides for proper ventilation. Do not place near flammable materials.
- Power Connection: Plug the power cord into a grounded electrical outlet. The appliance will emit a beep, and the display will illuminate briefly.
- First Use Cycle (Optional but Recommended): To eliminate any manufacturing odors, run the air fryer empty for about 10-15 minutes at 180°C. Ensure the area is well-ventilated during this process.
4. Operating Instructions
4.1. Powering On / Off
- To power on, plug the unit into an outlet. The display will show standby mode.
- Press the Simba bhatani kuti uvhure control panel.
- Kuti ubvise magetsi, pinda uye bata iyo Simba bhatani kwemasekonzi mashoma kusvika chiratidziro chadzima.
4.2. Using the Digital Display and Control Knob
The large touch screen display allows you to select cooking functions, adjust settings, and monitor cooking progress. The central control knob is used to fine-tune temperature and time.
- Preset Mabasa: The display features 6 preset cooking functions (e.g., Fries, Chicken, Steak, Fish, Bake, Dehydrate). Touch the corresponding icon to select a preset.
- Kugadzirisa Tembiricha: After selecting a preset or manual mode, touch the Tembiricha icon then rotate the control knob to adjust the temperature between 85°C and 200°C.
- Kugadzirisa Nguva: Bata iyo Nguva icon then rotate the control knob to set the cooking time.
- Kutanga / Kumbomira: Press the Tanga/Misa button to begin or temporarily stop cooking.
4.3. Dual Basket Cooking and Synchronized Finish
The SAF11DB allows you to cook two different foods simultaneously or a larger quantity of one food. When using the divider, each basket operates independently.
- Single Basket (11L): Remove the divider to use the full 11-litre capacity. Ideal for larger items like a whole chicken or turkey.
- Mabhasikiti maviri (2 x 5.5L): Insert the divider to create two separate cooking zones.
- Synchronized Cooking: If cooking two different items with different times/temperatures, use the SYNC function. Set the cooking parameters for each basket (Left 'L' and Right 'R'). The air fryer will automatically adjust the start times so both baskets finish cooking at the same time.
4.4. Chengeta Basa Rinodziya
After cooking is complete, the air fryer may automatically switch to a "Keep Warm" mode, or you can select it manually. This function maintains food at a serving temperature without overcooking.
4.5. Cooking Capacity Guidelines
- Machipisi: Up to 2.5 kg in the 11L basket.
- Teki: Up to 4.5 kg in the 11L basket.
- Adjust quantities based on food type and desired crispiness. Do not overfill baskets.
5. Kuchengetedza uye Kuchenesa
Kuchenesa nguva dzose kunoita kuti mudziyo wako wekugocha ushande zvakanaka uye kunoita kuti ugare kwenguva refu.
- Bvisa uye Kutonhorera: Nguva dzose sunungura fryer yemhepo kubva pamagetsi uye uibvumira kuti itonhore zvakakwana usati wachenesa.
- Cleaning Baskets and Divider: The cooking baskets and divider are removable and dishwasher safe. For hand washing, use warm water, a mild detergent, and a non-abrasive sponge.
- Cleaning Crisper Trays: The crisper trays can also be washed in the dishwasher or by hand with warm, soapy water.
- Kuchenesa Main Unit: Pukuta kunze kwemhepo fryer neadamp jira. Usashandise zvinhu zvinokwesha kana zvekukwesha. Usambofa wakanyika chinhu chikuru mumvura.
- Kuchenesa Kwemukati: Zvemukati memukati, pukuta nekushambadziraamp cloth. Remove any food residue.
- Kuchengeta: Ita shuwa kuti zvikamu zvese zvakachena uye zvakaoma usati wachengeta fryer yemhepo munzvimbo inotonhorera, yakaoma.
6. Kugadzirisa matambudziko
Kana iwe ukasangana nechero nyaya nemhepo fryer yako, ndapota tarisa kune anotevera akajairika matambudziko uye mhinduro:
| Dambudziko | Zvinogona Kukonzera | Solution |
|---|---|---|
| Air fryer haibatike. | Haina kubatirwa mukati; nyaya yekubuda kwemagetsi; kukanganisa kwemudziyo. | Ita shuwa kuti tambo yemagetsi yakanamirwa zvakachengetedzeka muchinhu chinoshanda. Tarisa muvharidzi wedunhu. Kana nyaya ikaramba iripo, bata rubatsiro rwevatengi. |
| Chikafu hachibikwa zvakaenzana. | Baskets are overcrowded; insufficient shaking/flipping; incorrect temperature/time. | Do not overfill baskets. Shake or flip food halfway through cooking. Adjust temperature and time as needed for specific recipes. |
| Utsi huchena huchibva mumudziyo. | Girisi zvakasara kubva kushandiswa kwekare; chikafu chine mafuta akawanda. | Clean the baskets and interior thoroughly after each use. For high-fat foods, drain excess fat during cooking. This is usually harmless. |
| Mudziyo unonhuhwirira panguva yekutanga kushandiswa. | Kugadzira zvisaririra zviri kutsva. | This is normal for first use. Run an empty cycle as described in Section 3. Ensure good ventilation. The smell will dissipate. |
7. Zvinotsanangurwa
| Model Number: | SAF11DB |
| Kugona | 11 Liters (or 2 x 5.5 Liters) |
| Simba / Wattage: | 1700 Watts |
| Voltage: | 220 Volts (AC) |
| Temperature Range: | 85°C kusvika 200°C |
| Material: | Metal |
| Dimensions (Chigadzirwa): | 48D x 44W x 38H masendimita |
| Chinhu Weight: | 8 kg |
| Special Features: | Automatic Shut-Off, Dual Zone Features, Programmable, Temperature Control |
8. Warranty uye Tsigiro
This Swan SAF11DB Air Fryer is covered by a manufacturer's warranty. Please refer to the warranty card included with your purchase for specific terms and conditions.
Spare Parts: Please note that spare part information is not available or provided at this time.
For technical support, service, or warranty claims, please contact Swan customer service through their official website or the contact information provided in your purchase documentation. When contacting support, please have your model number (SAF11DB) and proof of purchase ready.
