1. Nhanganyaya
This manual provides essential information for the safe and efficient operation of your DEMULLER 12000 BTU Mini Split Air Conditioner and Heater. Please read all instructions carefully before installation and use. This unit is designed to provide both cooling and heating for rooms up to 750 sq. ft.
Important Safety Notice: Professional installation is required for this appliance. Improper installation can lead to electric shock, fire, or serious injury. Always consult a licensed HVAC technician.
2. Setup uye Kuiswa
The DEMULLER Mini Split Air Conditioner and Heater comes with a comprehensive installation kit. Due to the complexity and safety requirements, professional installation by a licensed HVAC technician is mandatory for optimal performance and safety. Line-set vacuuming is required during installation.
2.1 Package Zviri mukati
Verify that all components listed below are included in your package. The unit typically ships in two separate boxes.
Tsanangudzo yemufananidzo This image displays the complete package contents for the DEMULLER Mini Split AC. Box 1 includes the indoor unit, remote control, hanging board, wall sheathing, and user manual. Box 2 contains the outdoor unit along with installation accessories such as putty, drain hose, connection pipes, communication wire, various screws, tape, and wall sleeves.
- Indoor Unit
- Outdoor Unit
- Remote Control
- User Manual
- Yakarembera Board
- Wall Sheathing
- Putty
- Dhonza Hose
- Connection Pipes (x2)
- Kutaurirana waya
- Zvikuru (x6)
- Expansion Screws (x6)
- Tepi
- Sleeve Yemadziro
2.2 Kuiswa Kwenyanzvi
For safety and to ensure proper functioning, the installation of this mini split system must be performed by a qualified and licensed HVAC professional. This includes proper electrical wiring, refrigerant line connections, and vacuuming of the line set.
Tsanangudzo yemufananidzo This image shows a professional HVAC technician carefully installing the outdoor condenser unit of a mini split air conditioner system. The technician is working on the exterior wall of a building, emphasizing the need for expert installation.
3. Operating Instructions
Your DEMULLER Mini Split AC offers multiple modes and settings for customized comfort. All functions are accessible via the included remote control and can be managed through the WiFi-enabled smart control feature.
3.1 Maitiro Okushandisa
The unit features 5 versatile operating modes:
Tsanangudzo yemufananidzo This image illustrates the various operating modes available on the DEMULLER Mini Split AC. Icons for Cool, Heat, Dry, Fan, Auto, and Eco modes are prominently displayed above the indoor unit, signifying its multi-functional design.
- Mamiriro Akanaka Provides cooling to lower room temperature.
- Heat Mode: Provides heating to raise room temperature.
- Yakaoma Mode: Inobvisa humidity mumhepo, kuderedza humidity mazinga.
- Fan Mode: Inotenderera mhepo isingatonhodze kana kudziyisa.
- Auto Mode: Automatically selects the appropriate mode (cooling or heating) based on the set temperature and current room temperature.
3.2 Kumhanyisa kweFani
Adjust the airflow intensity with 4 adjustable fan speeds: Low, Medium, High, and Turbo.
3.3 Quiet Operation and Sleep Mode
The unit is designed for ultra-silent operation, as low as 28 dB at low speed, ensuring a peaceful environment. The Sleep Mode further optimizes comfort and energy efficiency during nighttime hours.
Tsanangudzo yemufananidzo This image depicts a serene bedroom environment at night, highlighting the quiet operation of the indoor unit. Text overlays indicate 'Sleep Mode - 24 Timer' and a graphic illustrates sound levels, showing the unit operating below 20dB for an undisturbed sleep.
3.4 Kubatana kweWiFi
The unit is WiFi enabled, allowing for smart control via a compatible application on your smartphone. Refer to the separate WiFi setup guide for detailed instructions on connecting your device.
4. Kuchengeta
Regular maintenance ensures the longevity and efficiency of your mini split system. Always disconnect power to the unit before performing any maintenance.
4.1 Mhepo Sefa Yekuchenesa
The air filters in the indoor unit should be cleaned regularly (e.g., every 2-4 weeks, depending on usage) to maintain air quality and system efficiency. Refer to the detailed instructions in the full user manual for filter removal and cleaning procedures.
4.2 Outdoor Unit Inspection
Periodically inspect the outdoor unit for any obstructions (leaves, debris) around the condenser coils. Ensure proper airflow is maintained. Clean the coils gently if necessary, following professional guidelines.
5. Kugadzirisa matambudziko
If you encounter issues with your unit, please refer to the following basic troubleshooting steps. For complex problems, contact a qualified technician.
- Yuniti haibatike: Tarisa magetsi, circuit breaker, uye tarisa kuti mabhatiri eremote control anoshanda.
- Kutonhodza/kudziyisa kusina kukwana: Verify correct mode selection, set temperature, clean air filters, and ensure no obstructions to airflow.
- Mitsindo isina kujairika: Minor operational noises are normal. If loud or unusual noises occur, power off the unit and contact support.
- Kubuda kwemvura: Check the drain hose for blockages or improper installation.
6. Zvinotsanangurwa
Key technical specifications for the DEMULLER 12000 BTU Mini Split Air Conditioner and Heater.
Tsanangudzo yemufananidzo This image provides a detailed overview of the product's physical dimensions and technical specifications. It includes measurements for both the indoor and outdoor units, alongside a table listing crucial data such as 12000 BTU cooling capacity, 22 SEER2 rating, 230V voltage, 60Hz frequency, 750 sq. ft. coverage area, R32 refrigerant, various fan speeds, and recommended ambient temperature ranges for operation.
| Feature | Detail |
|---|---|
| Brand | DEMULLER |
| Model Number | YX-DEMULLER-12K SEER22-230V-Split AC |
| Cooling Capacity | 12000 BTU (Toni imwe) |
| Heating Capacity | 12000 BTU |
| SEER2 Rating | 22 MUONI2 |
| Voltage | 230 Volts |
| Wattage | 1450 watts |
| Noise Level (Indoor) | As low as 28 Decibels |
| Refrigerant | R-32 |
| Nzvimbo yekuvhara | Kusvika ku750 Sq. Ft. |
| Zviyero zveMukati meimba (D x W x H) | 7.5" x 33.46" x 11.4" |
| Zviyero zveChikamu chekunze (D x W x H) | 10.24" x 27.95" x 21.81" |
| Special Features | Dehumidifier, Fast Cooling, Heating & Cooling Function, Remote Controlled, WiFi Enabled |
7. Warranty uye Customer Support
For warranty information, please refer to the documentation included with your product or contact DEMULLER customer service. If you require technical assistance, replacement parts, or have any questions regarding your DEMULLER Mini Split Air Conditioner and Heater, please contact our customer support team. Ensure you have your model number and purchase details available when contacting support.
Contact Information:
- Tarisa magwaro ekutenga kwako kuti uwane ruzivo rwekuonana.
- Visit the official DEMULLER webnzvimbo yekutsigira zviwanikwa.
